ADVANTAGES
OPERATING RANGE: 0.37 - 7.5kw, 3-phase, 380-480V AC
TECHNICAL SPECIFICATION OF VFD
Power Supply
- 3-phase 380/400/415/440/480 V ±10%.
- 50/60 Hz Input Frequency.
Overload
- 150% of rated current upto 60 sec.
Programmable Digital Inputs/ Outputs
- DI — 6 nos.
- DO — 01 no.
- Relay O/P - 01 no.
Analog Inputs
- O1 nos. — Voltage and Current
(0-±10 V DC and 0/4 -20 mA).
Mechanical Dimensions
- Upto 1.5kW - 250x200x150 mm.
- Above 1.5kW - 300x260x150 mm.
OPTIONS AND ACCESSORIES
- Field bus Communication.
- Brake Resistor.
- External electro-mechanical brake control and supply.
